Single-machine rolled cold-rolled steel plate
The single-machine cold-rolled hardened steel plate is produced using a six-roll reversible cold rolling mill. The company currently has 7 such mills with an annual capacity of 1.68 million tons. The mills are equipped with a segmented cooling system and AGC automatic closed-loop thickness control, ensuring high dimensional accuracy and excellent plate shape, and can reliably meet the precision and performance requirements of high-end steel plates.
Single-machine rolled cold-rolled steel plateProduct introduction
The single-machine cold-rolled hardened steel plate is produced using a six-roll reversible cold rolling mill. The company currently has 7 such mills with an annual capacity of 1.68 million tons. The mills are equipped with a segmented cooling system and AGC automatic closed-loop thickness control, ensuring high dimensional accuracy and excellent plate shape, and can reliably meet the precision and performance requirements of high-end steel plates.
Application areas
It is widely used in industries with high requirements for sheet metal precision and flatness, such as metal stamping, home appliance housings, automotive parts, electronic appliances, and high-end metal products.
Product parameters
thickness Thickness |
0.09mm-2.50mm |
width Width |
700mm-1250mm |
Product brand Product Grade |
SPHC/SPHD/SPHE/Q195L/08AL/IF |
Steel coil inner diameter Inner diameter of steel coil |
508mm/610mm |
outer diameter of steel coil Outer diameter of steel coil |
≤2000mm |
Maximum weight Maximum weight |
≤22T |
standard Standard |
Japanese Standard Cold Steel Annealed and Hardened SPCC |
